G-Tools 125-2 Speed Fan + PK Eco Filter

A set of the GT 125 two-speed fan with a Prima Klima K2601 flat carbon filter whose optimum is 360 m³/h. Both parts on 125 mm, mounting bracket included.

Three ways to join the two

Fan and filter share a flange size, which means you can couple them directly with no reducer. There are three usual methods and they differ in more than convenience.

A length of ducting between them is the simplest. A clamp each end and done. The drawback is that flexible ducting is ribbed inside and so adds resistance, so keep the piece short.

A coupling sleeve joins the two flanges tightly. That is cleanest for airflow, since almost no extra length sits between them, and the whole becomes one rigid block you hang in one go.

A rubber sleeve does the same while interrupting vibration transfer between fan and filter. That is the quietest option, because the filter body then does not ring along as a soundboard.

Which you choose depends on what matters more. For least resistance and a compact assembly, take the coupling sleeve. If your set-up is in a home where noise counts, take rubber.

In every case, make sure the filter is on the suction side and that you support the weight of both parts separately.

Technical Specifications:

• Set: fan, carbon filter and mounting bracket
• Fan: GT 125, balanced EBM Papst motor, quiet housing
• Settings: two
• Filter: Prima Klima K2601 flat
• Optimal filter flow: 360 m³/h
• Maximum filter flow: 480 m³/h
• Filter height: 250 mm
• Flange, both parts: 125 mm

Frequently asked questions

Do I need a reducer?
No, both parts are 125 mm.

Which coupling is quietest?
A rubber sleeve, since it does not pass vibration to the filter body.

Why a flat filter?
It is shorter than the standard model at the same capacity, which saves height.
